Muelle de carga pesada M99MC1988
  • Muelle de carga pesada M99MC1988

Muelle de carga pesada M99MC1988

M99MC1988
Rating
Muelle de carga pesada M99MC1988
€309.92
Maximum 8 working days
Quantity
This product is in stock

Compare



Download PDF
Description

Muelle de carga pesada heavy spring

Material 51CrV4

Pintado color negro

Extremos rectificados

tolerancias de acuerdo a DIN 2095

Product Details
M99MC1988

Data sheet

FREE LENGTH
185
OUTSIDE DIAMETER
140
INSIDE DIAMETER
102
WIRE DIAMETER
19
ACTIVE COILS
5.5
TOTAL COILS
7
SPRING RATE (K)
15.26
RAW MATERIAL
51CrV4
ENDS
CLOSED & GROUND
SURFACE COATING
BLACK COLOUR PAINTED
SOLID LENGTH
133
LOAD LENGHT L1
159
LOAD AT L1
3969
PITCH
33.64
SPRING INDEX
6.37
