Compression spring M01MCPF4924
  • Compression spring M01MCPF4924

Compression spring M01MCPF4924

M01MCPF4924

Compression spring M01MCPF4829

Volume discounts

Quantity Unit discount You Save
10 €0.50 Up to €5.00
20 €1.00 Up to €20.00
30 €1.50 Up to €45.00
€133.10
VAT not included Maximum 8 working days
Quantity
This product is in stock

Compare



Download PDF
We deliver our products to European Union countries. To get 0% VAT for intra-community transaction provide us your valid EU VAT number
Description
  • Compression spring acc/DIN 2095
  • Designed according to EN 13906-1: 2002
  • Made in Spain
Product Details
M01MCPF4924

Data sheet

FREE LENGTH
100
OUTSIDE DIAMETER
44.25
INSIDE DIAMETER
28.25
WIRE DIAMETER
8
ACTIVE COILS
5.65
TOTAL COILS
7.65
SPRING RATE (K)
155
RAW MATERIAL
EN 10270-1 SH
ENDS
CLOSED & GROUND
SURFACE COATING
PROCER PLUS
SOLID LENGTH
61.2
4 other products in the same category:
Muelle de compresion M01MC3040135 Quick view

Reference: M01MC1069001

Compression spring M01MC1069001 CrSi

Compression spring M01MC1069001 CrSi

FREE LENGTH: 22
OUTSIDE DIAMETER: 13
INSIDE DIAMETER: 6.8
WIRE DIAMETER: 3.1
ACTIVE COILS: 3.85
TOTAL COILS: 9.7
SPRING RATE (K): 99.92
RAW MATERIAL: EN 10270-2 FDSICR
ENDS: CLOSED & GROUND
SURFACE COATING: NO PROTECTION
SOLID LENGTH: 18.25
Price €3.63
More
Muelle de Compresión M01LE2055 Quick view

Reference: M01MCPF2535

Compression spring M01MCPF2535

Compression spring

FREE LENGTH: 18.5
OUTSIDE DIAMETER: 3.6
INSIDE DIAMETER: 2.30
WIRE DIAMETER: 0.65
ACTIVE COILS: 10.5
TOTAL COILS: 12.5
SPRING RATE (K): 0.675
RAW MATERIAL: EN 10270-1 SH
ENDS: CLOSED NOT GROUND
SURFACE COATING: NO PROTECTION
SOLID LENGTH: 8.775
Price €2.42
More
Muelle de compresion M01MC6260002 Quick view

Reference: M01MC5520005

Compression spring M01MC5520005

Compression spring

FREE LENGTH: 26
OUTSIDE DIAMETER: 8.35
INSIDE DIAMETER: 7.15
WIRE DIAMETER: 0.6
ACTIVE COILS: 6.25
TOTAL COILS: 8.25
SPRING RATE (K): 0.33
RAW MATERIAL: EN 10270-3 1.4310
ENDS: CLOSED NOT GROUND
SURFACE COATING: NO PROTECTION
SOLID LENGTH: 5.5
Price €3.00
More
Muelle de compresion M01MC3040135 Quick view

Reference: M01MC7760001

Compression spring M01MC7760001 INCONEL 718

Compression spring M01MC7760001 INCONEL 718

FREE LENGTH: 70.1
OUTSIDE DIAMETER: 32.77
INSIDE DIAMETER: 26.77
WIRE DIAMETER: 3.00
ACTIVE COILS: 7.7
TOTAL COILS: 9.7
SPRING RATE (K): 1.99
RAW MATERIAL: TITANIUM GR.5
ENDS: CLOSED & GROUND
SURFACE COATING: ELECTROPOLISHED
SOLID LENGTH: 29.07
Price €24.00
More
