Tension spring M02MCPF4926

M02MCPF4926

Tension spring M02MCPF4926

€30.00
VAT not included Maximum 8 working days
Quantity
This product is in stock

The minimum purchase order quantity for the product is 2.

Compare



Download PDF
We deliver our products to European Union countries. To get 0% VAT for intra-community transaction provide us your valid EU VAT number
Description

Designed according to EN 13906-2: 2001 & DIN 2089

Made in Spain

Product Details
M02MCPF4926

Data sheet

FREE LENGTH
OUTSIDE DIAMETER
11
WIRE DIAMETER
2
ACTIVE COILS
220
RAW MATERIAL
EN 10270-1 SH
SURFACE COATING
NO PROTECTION
