  • Muelle traccion- Tension spring - Springmakers.net

Tension spring M02MC0900034

M02MC0900034

Tension spring M02MC0900034

€2.80
VAT not included 1
Quantity
This product is in stock

Compare



Download PDF
We deliver our products to European Union countries. To get 0% VAT for intra-community transaction provide us your valid EU VAT number
Description

Standard extension  spring

Designed according to  EN 13906-2: 2001

Made in Spain

Product Details
M02MC0900034

Data sheet

LOOPS TYPE
OFF SIDE LOOPS
FREE LENGTH
24
OUTSIDE DIAMETER
5.3
WIRE DIAMETER
0.6
ACTIVE COILS
25
SPRING RATE (K)
0.512
RAW MATERIAL
EN 10270-1 SH
SURFACE COATING
NO PROTECTION
INITIAL TENSION
3
LOAD LENGHT L1
28
LOAD AT L1
5.1
4 other products in the same category:
Extension spring M02MCPF4823 Quick view

Reference: M02MCPF4823

Extension spring M02MCPF4823

Extension spring

FREE LENGTH: 53.5
OUTSIDE DIAMETER: 4.5
WIRE DIAMETER: 0.5
ACTIVE COILS: 92
SPRING RATE (K): 0.1
RAW MATERIAL: EN 10270-3 1.4310
SURFACE COATING: NO PROTECTION
INITIAL TENSION: 1.5
LOAD LENGHT L1: 75
LOAD AT L1: 3.58
Price €10.50
More
Muelle traccion- Tension spring - Springmakers.net Quick view

Reference: M02MCPF4994

Tension spring M02MCPF4994

Muelle de tracción

FREE LENGTH: 500
OUTSIDE DIAMETER: 3.5
WIRE DIAMETER: 0.75
ACTIVE COILS: 666
SPRING RATE (K): 0.233
RAW MATERIAL: EN 10270-1 SH
SURFACE COATING: NO PROTECTION
INITIAL TENSION: 5
LOAD LENGHT L1: 510
LOAD AT L1: 7.3
Price €78.50
More
Tension spring M02MCPF4921... Quick view

Reference: M02MCPF4921

Tension spring M02MCPF4921 DIN2089/1.4*13.6*44.0

Tension spring M02MCPF4921 DIN2089/1.4*13.6*44.0

FREE LENGTH: 44
OUTSIDE DIAMETER: 13.6
WIRE DIAMETER: 1.4
ACTIVE COILS: 15
SPRING RATE (K): 1.44
RAW MATERIAL: EN 10270-1 SH
SURFACE COATING: NO PROTECTION
INITIAL TENSION: 4
LOAD LENGHT L1: 60
LOAD AT L1: 27
Price €4.00
More
Tension spring M02MCPF4918 DIN2089/0.7*6.8/52.8 Quick view

Reference: M02MCPF4918

Tension spring M02MCPF4918 DIN2089/0.7*6.8/52.8

Tension spring M02MCPF4918 DIN2089/0.7*6.8/52.8

FREE LENGTH: 52.8
OUTSIDE DIAMETER: 6.8
WIRE DIAMETER: 0.7
ACTIVE COILS: 58.5
SPRING RATE (K): 0.184
RAW MATERIAL: EN 10270-1 SH
SURFACE COATING: NO PROTECTION
INITIAL TENSION: 2
LOAD LENGHT L1: 99
LOAD AT L1: 10.51
Price €4.00
More
